RAG Architecture, Explained: How to Build Retrieval-Augmented Generation That Actually Works

A large language model only knows what was in its training data. It has never seen your product catalogue, your refund policy, last week's pricing change or the PDF your operations team wrote in March. Ask it about any of those and it will either say it doesn't know or, worse, confidently make something up.

Retrieval-Augmented Generation (RAG) fixes this without retraining the model. At question time, the system retrieves the few passages from your own data that are most relevant to the question, augments the prompt with them, and lets the model generate an answer grounded in that text — ideally with citations back to the source.

That one-sentence description hides a lot of engineering. Most RAG systems that disappoint in production don't fail because of the model; they fail because the wrong passages were retrieved. This guide walks through the full architecture, the decisions at each step, and how to know whether it's working.

What is RAG? A one-paragraph definition

Retrieval-Augmented Generation is an AI architecture that answers questions by first searching a knowledge base for relevant passages and then passing those passages to a large language model as context. The model's answer is grounded in your data rather than in what it memorised during training, which makes answers more accurate, current and verifiable. The knowledge base is usually a vector database of document chunks, and the search usually combines semantic (vector) and keyword matching.

Typical RAG use cases include customer-support assistants over a help centre, internal knowledge assistants over policies and wikis, sales assistants over product documentation, and research tools over contracts, reports or papers.

RAG vs fine-tuning vs a giant prompt

There are three common ways to give a model knowledge it doesn't have. They solve different problems:

	RAG	Fine-tuning	Long-context prompt
What it changes	What the model reads at answer time	The model's weights	What the model reads at answer time
Best for	Facts, documents, data that changes	Style, format, a narrow skill	A small, fixed set of documents
Freshness	Update the index in seconds	Retrain to update	Edit the prompt
Citations	Natural — you know which chunks were used	Not possible	Possible but vague
Cost per question	Low (only relevant chunks are sent)	Low	High (everything is sent, every time)
Scales to	Millions of documents	—	What fits in the context window

The short version: use RAG for knowledge, fine-tuning for behaviour. If your whole knowledge base is a few pages, skip RAG and put it in the prompt. Once it's larger than that, or changes often, or needs per-user permissions, you want retrieval.

The two pipelines inside every RAG system

Every RAG system is really two pipelines that share a vector index. One runs ahead of time (or continuously) to prepare your data. The other runs on every question.

INGESTION  (offline / on every data change)

  Sources ──► Load & clean ──► Chunk ──► Embed ──► Store
  (docs, DB,     (text +        (split    (text →   (vector index
   tickets,       metadata)      into      vectors)   + metadata)
   web pages)                    passages)

QUERY  (on every question)

  Question ──► Rewrite ──► Retrieve ──► Rerank ──► Prompt ──► Generate ──► Answer
               (optional)  (vector +    (keep the  (question   (LLM)       + citations
                            keyword)     best 5–8)  + chunks)

Let's go through each stage.

1. Loading and cleaning

Garbage in, garbage retrieved. Before anything is embedded, turn every source into clean text plus metadata:

• Extract text properly. PDFs, slides and scanned documents need real parsing (and OCR for scans). Tables are the usual casualty — convert them to Markdown or one row per line so they survive.
• Strip the noise. Navigation menus, cookie banners, repeated headers and footers all pollute embeddings.
• Keep metadata. Source URL, title, section heading, author, last-updated date, product, language and — critically — who is allowed to see it. You'll filter on these later.

2. Chunking

You can't embed a 60-page manual as one vector — the meaning gets averaged into mush, and you couldn't fit it all in the prompt anyway. So documents are split into chunks. Chunking is the single most underrated decision in RAG.

• Fixed-size with overlap. Split every ~300–800 tokens with 10–20% overlap so sentences on a boundary aren't lost. Simple, and a fine baseline.
• Structure-aware. Split on headings, sections, list items or FAQ entries so each chunk is one coherent idea. Almost always better than fixed-size for documentation.
• Semantic chunking. Start a new chunk where the topic shifts, detected by embedding similarity between sentences. Useful for long, unstructured prose.
• Parent–child (small-to-big). Embed small chunks for precise matching, but send the larger parent section to the model so it has the surrounding context.
• Contextual chunk headers. Prepend the document title and section path to each chunk before embedding (e.g. "Returns policy › International orders › …"). A chunk that just says "this must be done within 14 days" is useless on its own; with a header it becomes findable.

Rule of thumb: a chunk should make sense if a person read it with no other context. If it doesn't, it won't make sense to the retriever either.

3. Embeddings

An embedding model turns text into a vector — a list of a few hundred to a few thousand numbers — such that texts with similar meaning end up close together. "How do I get my money back?" lands near "Refund policy" even though they share no words.

• Use the same model for documents and questions. Vectors from different models aren't comparable.
• Pick for your language and domain. Check retrieval benchmarks (the MTEB leaderboard is the usual reference), then test on your own data — see the evaluation section below.
• Changing models means re-embedding everything. Store the model name alongside each vector so migrations are deliberate.
• Mind the dimensions. Bigger vectors can be slightly more accurate but cost more storage and search time. Many models let you truncate dimensions with little loss.

4. The vector store

The vector store holds your chunks, their vectors and their metadata, and answers "which vectors are closest to this one?" quickly using an approximate nearest-neighbour index (HNSW is the most common).

Options range from dedicated vector databases (Qdrant, Pinecone, Weaviate, Milvus, Chroma) to adding vectors to the database you already run. If you're on PostgreSQL, pgvector keeps everything — data, metadata, permissions and vectors — in one place, which removes a whole class of sync bugs:

create extension if not exists vector;

create table chunks (
  id          bigserial primary key,
  document_id text not null,
  content     text not null,
  metadata    jsonb not null default '{}',
  embedding   vector(1536) not null
);

create index on chunks using hnsw (embedding vector_cosine_ops);

-- top 20 chunks for a question, limited to one product
select id, content, 1 - (embedding <=> $1) as similarity
from chunks
where metadata->>'product' = 'billing'
order by embedding <=> $1
limit 20;

A dedicated vector database earns its place at very large scale, when you need advanced filtering and quantisation, or when search load would compete with your transactional database.

Choosing a vector database

Option	Good fit when	Things to consider
pgvector (PostgreSQL)	You already run Postgres; you want data, permissions and vectors in one place	Tune HNSW settings and memory as the index grows
Qdrant	You want a fast open-source engine with strong payload filtering, self-hosted or managed	A second datastore to keep in sync
Pinecone	You want a fully managed, serverless service with minimal operations	Hosted only; costs scale with usage
Weaviate / Milvus	You need very large collections, built-in hybrid search or many tenants	More moving parts to operate if self-hosted
Chroma	Prototypes, notebooks and local development	Plan your production store early

In practice, the quality of your chunks and retrieval strategy matters far more than which of these you pick.

5. Retrieval: dense, sparse and hybrid

Pure vector (dense) search is great at meaning but surprisingly bad at exact terms: product codes, error numbers, names, acronyms. Keyword (sparse) search such as BM25 is the opposite. So production systems usually run both and merge the results — hybrid search.

The standard way to merge is Reciprocal Rank Fusion (RRF): each result scores 1 / (60 + rank) in each list, and the scores are summed. It needs no tuning and works well.

Two other retrieval levers matter as much as the algorithm:

• Metadata filters. Restrict the search to the right product, language, date range — and to documents the current user is permitted to see. Permission filtering must happen in the retrieval query, never by asking the model to ignore things.
• How many to fetch. Retrieve generously at this stage (20–50 candidates) and let the reranker narrow it down.

6. Reranking

Embedding search compares a question vector with chunk vectors that were computed independently, which is fast but approximate. A reranker (a cross-encoder) reads the question and each candidate chunk together and scores how well the chunk actually answers it. It's slower, so you only run it on the shortlist.

Retrieve 30–50, rerank, keep the top 5–8. In our experience this is the single cheapest large improvement you can make to a RAG system that "sort of works".

7. Building the prompt and generating

Finally, the chosen chunks go into the prompt with clear instructions. A solid starting template:

You answer questions using ONLY the sources below.

Rules:
- If the sources don't contain the answer, say you don't know.
- Cite the sources you used like [1], [2].
- Quote numbers, dates and prices exactly as written.

Sources:
[1] Returns policy › International orders
Items shipped outside the UK can be returned within 30 days ...

[2] Help centre › Refund timelines
Refunds are issued to the original payment method within 5–10 business days ...

Question: How long do I have to return an order shipped to Germany?

Put the most relevant chunks first, keep instructions short and explicit, and always give the model permission to say "I don't know". A RAG system that admits ignorance is far more trustworthy than one that improvises.

Advanced patterns worth knowing

• Query rewriting. Users ask vague, conversational questions ("what about the other one?"). Have a fast model rewrite the question into a standalone search query using the chat history before retrieving.
• Multi-query and HyDE. Generate several phrasings of the question — or a hypothetical answer — and search with each, then fuse the results. Helps when users and documents use different vocabulary.
• Agentic RAG. Give the model retrieval as a tool instead of retrieving once up front. It can search, read, decide it needs more, and search again — essential for multi-step questions like "compare our 2025 and 2026 pricing for annual plans".
• GraphRAG. Extract entities and relationships into a knowledge graph, so questions about connections ("which suppliers affect product X?") or whole-corpus themes can be answered, not just look-ups.
• Multi-tenant RAG. When several customers or products share one system, every chunk carries a tenant ID and every query is filtered by it — or each tenant gets its own collection. Isolation is enforced by the retriever, never by the prompt.

Keeping the index fresh

A RAG system is only as current as its index. Treat ingestion as a sync service, not a one-off script:

• Detect changes with webhooks, database change-data-capture, or polling an updated_at column.
• Hash each chunk's content and only re-embed chunks whose hash changed — re-embedding everything on every change gets expensive fast.
• Handle deletes. When a document is removed or unpublished, its chunks must go too, or the assistant will keep quoting it.
• Upsert by stable IDs (document ID + chunk position) so updates replace rather than duplicate.

RAG over structured data: when to use SQL instead

RAG is built for unstructured text. If the question is "how many orders shipped late last month?", embedding database rows and searching them is the wrong tool — the answer needs counting and filtering, not similarity. For structured data, let the model write a query instead (text-to-SQL) against a read-only database user and a documented schema, or expose specific, safe query tools. Many real assistants combine both: RAG for policies and documentation, SQL tools for numbers and records.

A latency and cost budget

Every stage adds time and money. Typical ranges (they vary by provider and scale):

Stage	Typical latency	How to keep it down
Query rewriting	200–500 ms	Use a small, fast model; skip it for first messages
Embedding the question	50–150 ms	Cache embeddings for repeated questions
Vector + keyword search	10–100 ms	Proper indexes, metadata filters, sensible top-k
Reranking	100–400 ms	Rerank 30–50 candidates, not hundreds
Generation	1–5 s	Stream the answer; send fewer, better chunks

Streaming the response hides most of this: users see the first words almost immediately. On cost, the biggest lever is sending fewer tokens of context — which is exactly what good retrieval and reranking give you.

Security and privacy in RAG

• Permission-aware retrieval. Store access rules as metadata and filter on them in every query, so a user can only ever retrieve what they could open themselves.
• Prompt injection in documents. Retrieved text can contain instructions ("ignore previous rules…"). Treat it as data, keep system instructions separate, and never let retrieved text alone trigger actions.
• Sensitive data. Decide what should never be indexed — passwords, personal data you don't need, secrets in old documents — and filter it at ingestion.
• Data residency. Check where your embedding model, vector store and LLM process data if you have regulatory obligations.

How to evaluate a RAG system

"It looks good when I try it" is not an evaluation. Build a golden set of 50–200 real questions, each with the correct answer and the document(s) that contain it. Then measure the two halves separately:

Stage	Metric	Question it answers
Retrieval	Recall@k / hit rate	Was the right chunk in the top k at all?
Retrieval	MRR	How high up was it ranked?
Retrieval	Context precision	How much of what we sent was actually relevant?
Generation	Faithfulness	Is every claim in the answer supported by the retrieved text?
Generation	Answer relevance	Does the answer address the question that was asked?
End to end	Correctness	Does it match the reference answer?

Libraries such as Ragas and DeepEval compute the generation metrics using an LLM as the judge. Run the golden set on every change to chunking, embeddings, prompts or models, and you'll know immediately whether a change helped. We cover evals in depth in our guide to LLM benchmarks and evals.

Common failure modes, and what usually fixes them

Symptom	Likely cause	Fix
Can't find answers that are definitely in the docs	Poor chunking or parsing; exact terms missed	Structure-aware chunks, contextual headers, hybrid search
Finds the right document, wrong part of it	Chunks too large or no reranker	Smaller chunks + parent–child, add a reranker
Answers with outdated information	Stale index, deletes not synced	Change detection, content hashing, delete handling
Confident answers not in the sources	Prompt allows guessing	Explicit "only from sources" rule, require citations, check faithfulness
Fails on follow-up questions	Retrieval uses the raw follow-up text	Rewrite the query using chat history
Shows one customer another's data	Permissions applied after retrieval (or not at all)	Filter by tenant/permissions inside the retrieval query

A production checklist

• Clean parsing, with tables and headings preserved
• Structure-aware chunks with contextual headers
• Hybrid search plus a reranker
• Permission and tenant filters inside the retrieval query
• An incremental sync pipeline that handles updates and deletes
• Citations in every answer, and permission to say "I don't know"
• A golden set run on every change, and logging of real questions to grow it
• Latency and cost tracked per stage, not just end to end

RAG glossary

• Chunk — a passage of a document, embedded and retrieved as one unit.
• Embedding — a vector of numbers representing the meaning of a piece of text.
• Vector database — a store that finds the vectors most similar to a query vector.
• HNSW — the most common approximate nearest-neighbour index for fast vector search.
• BM25 — a classic keyword-ranking algorithm used for sparse search.
• Hybrid search — combining vector and keyword search, typically with Reciprocal Rank Fusion.
• Reranker — a cross-encoder model that rescores candidate chunks against the question.
• Faithfulness — whether every claim in an answer is supported by the retrieved context.

RAG is less about any one clever technique and more about getting a dozen ordinary decisions right. Get retrieval right and almost any modern model will give good answers; get it wrong and no model can save you.
